Accelerator pedal for BMW 6 Series E24 635CSi
This Accelerator pedal technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 635CSi. It includes part names, part numbers and all associated mounting hardware.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | ONLY APPLIES TO EH-CONTROL | |||||||||
| 01 | Operating lever | 1 | 09/1984 | 06/1987 | 13541274059 | ENDED | Shop at ECS Tuning | |||
| 03 | Bearing accelator bowden cable | SCHWARZ | 2 | 09/1984 | 06/1987 | 13541747519 | $0.58 | Shop at ECS Tuning | ||
| 04 | Retainer spring | 1 | 09/1984 | 06/1987 | 13541274065 | ENDED | Shop at ECS Tuning | |||
| 05 | Bush | 2 | 09/1984 | 06/1987 | 13111276960 | ENDED | Shop at ECS Tuning | |||
| 06 | Stopper | 1 | 09/1984 | 06/1987 | 13541274066 | ENDED | Shop at ECS Tuning | |||
| 07 | Circlip | 7,0 | 2 | 09/1984 | 06/1987 | 07119905858 | $0.96 | Shop at ECS Tuning | ||
| 09 | Washer | A6,4-200HV-ZNS3 | 1 | 09/1984 | 06/1987 | 07119903791 | $0.11 | Shop at ECS Tuning | ||
| 10 | Spacer bush | 1 | 09/1984 | 06/1987 | 13541274067 | ENDED | Shop at ECS Tuning | |||
| 11 | Stud bolt | M6X50 | 1 | 09/1984 | 06/1987 | 07129902312 | Shop at ECS Tuning | |||
| 12 | Retainer spring | 1 | 09/1984 | 06/1987 | 13541270886 | $1.33 | ENDED | Shop at ECS Tuning | ||
| 13 | Bush | 1 | 09/1984 | 06/1987 | 13541266289 | ENDED | Shop at ECS Tuning | |||
| 14 | Circlip | 8,4X13 | 1 | 09/1984 | 06/1987 | 13541267663 | ENDED | Shop at ECS Tuning | ||
| 15 | Hex nut | M8X1 | 1 | 09/1984 | 06/1987 | 13541267664 | $1.55 | ENDED | Shop at ECS Tuning | |
| 16 | Shift | 1 | 09/1984 | 06/1987 | 13541705473 | $29.64 | ENDED | Shop at ECS Tuning | ||
| 17 | Angle indicator | 1 | 09/1984 | 06/1987 | 13621287731 | $317.11 | Shop at ECS Tuning | |||
| 18 | Washer | 9X4,3X0,8-200HV | 2 | 09/1984 | 06/1987 | 07119904205 | $0.07 | Shop at ECS Tuning | ||
| 19 | Cheese-head screw | M4X20-8.8-ZNFE | 2 | 09/1984 | 06/1987 | 07119903004 | Shop at ECS Tuning | |||
| 19 | Fillister-head screw | M4X19 | 2 | 09/1984 | 06/1987 | 13541705475 | $0.11 | ENDED | Shop at ECS Tuning | |
| 20 | Holder | 1 | 09/1984 | 06/1987 | 13111289928 | $3.02 | Shop at ECS Tuning | |||
| 21 | Microswitch | 2 | 09/1984 | 06/1987 | 13631288217 | $25.80 | Shop at ECS Tuning | |||
| 22 | Lock plate | 1 | 09/1984 | 06/1987 | 13541705476 | ENDED | Shop at ECS Tuning | |||
| 23 | Washer | A3,2 | 2 | 09/1984 | 06/1987 | 07119931015 | $0.09 | Shop at ECS Tuning | ||
| 24 | Spring washer | B3 | 2 | 09/1984 | 06/1987 | 07119933017 | $0.13 | Shop at ECS Tuning | ||
| 25 | Fillister-head screw | 2 | 09/1984 | 06/1987 | 13541705479 | $0.33 | ENDED | Shop at ECS Tuning | ||
| 26 | Circular connector | D2,1 | 2 | 09/1984 | 06/1987 | 61131368620 | $1.23 | ENDED | Shop at ECS Tuning | |
| 27 | Cable socket round female | D2,1 | 1 | 09/1984 | 06/1987 | 61131368621 | $2.25 | Shop at ECS Tuning | ||
| 28 | Plug housing | 1 | 09/1984 | 06/1987 | 61131372380 | $6.16 | ENDED | Shop at ECS Tuning | ||
