Fuel tank breather valve for BMW MINI Clubman F54 Cooper (2019)
This Fuel tank breather valve technical drawing provides a detailed breakdown of the assembly for the MINI Clubman F54 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Fuel tank breather valve | 1 | 13907621174 | Shop at ECS Tuning | ||||||
| 02 | fuel tank breather line | 1 | 13907626118 | Shop at ECS Tuning | ||||||
| 03 | Fuel tank breath.line with resonator | 1 | 07/2017 | 13908670276 | Shop at ECS Tuning | |||||
| 04 | Fixing clamp | D=12-14/B=5 | 1 | 12527578321 | $1.08 | Shop at ECS Tuning | ||||
| 05 | Tubing support | 1 | 34327698478 | $1.48 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Clubman F54 Cooper Fuel tank breather valve?
- This technical diagram illustrates the Fuel tank breather valve within the Fuel preparation system group for the MINI Clubman F54 Cooper produced during 2019. It provides a detailed exploded view of the components, identifying key parts such as the Fuel tank breather valve (Part #13907621174).
- Which models use the hardware listed in this Fuel tank breather valve?
- The hardware and components featured in the Fuel tank breather valve are specific to the MINI Clubman F54 Cooper produced during 2019. These technical specifications ensure that parts like the Fuel tank breather valve (13907621174) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Fuel tank breather valve assembly?
- Each item in the Fuel tank breather valve corresponds to the numbered list below the illustration. For the MINI Clubman F54 Cooper, you can identify the Fuel tank breather valve by locating its position on the schematic, which then links to the official BMW part number 13907621174 for the Fuel preparation system section.
