Fuel tank for BMW 2500-3.3Li 2800 (1971)
This Fuel tank technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 2800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Lockable filler cap | 1 | 08/1968 | 02/1977 | 16111106486 | $38.38 | ENDED | Shop at ECS Tuning | ||
| 01 | Lockable filler cap | 1 | 08/1968 | 02/1977 | 16111106487 | $32.92 | Shop at ECS Tuning | |||
| 02 | Lockable filler cap (code) | 1 | 08/1968 | 02/1977 | 16111115396 | $112.72 | ENDED | Shop at ECS Tuning | ||
| 03 | Key gas filler cap (code) | KOEHLER | 1 | 08/1968 | 02/1977 | 16111103693 | ENDED | Shop at ECS Tuning | ||
| 03 | Key gas filler cap (code) | HAUCK | 1 | 08/1968 | 02/1977 | 16119558332 | ENDED | Shop at ECS Tuning | ||
| 04 | Rubber seal | 1 | 08/1968 | 02/1977 | 16111179680 | $6.70 | Shop at ECS Tuning | |||
| 05 | Rubber seal | 1 | 16111179680 | $6.70 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
