Cooling system-external Radiator for BMW 6 Series F13 640i (2015)
This Cooling system-external Radiator technical drawing provides a detailed breakdown of the assembly for the 6 Series F13 640i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Hot-climate version and High speed synchronisation |
S823A=No S840A=No |
||||||||
| 03 | Clip | RECHTS | 1 | 17127613139 | Shop at ECS Tuning | |||||
| 03 | Clip | LINKS | 1 | 17127613140 | Shop at ECS Tuning | |||||
| 04 | Hose, radiator | 1 | 09/2013 | 17128614881 | Shop at ECS Tuning | |||||
| 05 | Coolant hose | 1 | 09/2013 | 17128614880 | Shop at ECS Tuning | |||||
| 06 | Coolant hose | 1 | 09/2013 | 17128614879 | Shop at ECS Tuning | |||||
