Lambda Probe Fixings for BMW 5 Series G60 Sedan 530iX (2025)
This Lambda Probe Fixings technical drawing provides a detailed breakdown of the assembly for the 5 Series G60 Sedan 530iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Monitoring oxygen sensor | 1 | 11788686980 | Shop at ECS Tuning | ||||||
| 02 | Primary oxygen sensor | 1 | 11788686979 | Shop at ECS Tuning | ||||||
| 03 | Holder | 1 | 11785A189F9 | Shop at ECS Tuning | ||||||
| 04 | ASA screw, self-threading | M6X18 | 2 | 11367609963 | Shop at ECS Tuning | |||||
| 05 | Clip for corrugated tubing | 1 | 12527620159 | Shop at ECS Tuning | ||||||
| 06 | Fixing clamp | A=3,5 - 6,0MM | 1 | 07147547239 | $0.58 | Shop at ECS Tuning | ||||
| 07 | Clip | 1 | 12521437136 | $0.63 | Shop at ECS Tuning | |||||
| 08 | Cable holder | 1 | 07147590403 | Shop at ECS Tuning | ||||||
| 09 | Clip | 15-19 | 1 | 07147568538 | $3.49 | Shop at ECS Tuning |
