ZF s5-16 inner gear shifting parts for BMW 2500-3.3Li 2500 (1971)

This ZF s5-16 inner gear shifting parts technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 2500. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.

ZF s5-16 inner gear shifting parts
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Shifting fork 1st to 4th gear 1 23311201347 ENDED Shop at ECS Tuning
02 O-ring 6 23311201346 $2.51 ENDED Shop at ECS Tuning
03 Pin 2 23311201349 ENDED Shop at ECS Tuning
05 Hex bolt M6X12-8.8-ZNNIV 6 07119905524 $0.27 Shop at ECS Tuning
06 Selector rod 1 23311201363 ENDED Shop at ECS Tuning
07 Pin 2 23311201343 ENDED Shop at ECS Tuning
08 Shifting fork 1st and reverse gear 1 23311201337 ENDED Shop at ECS Tuning
09 Selector rod 1 23311201360 ENDED Shop at ECS Tuning
10 Pin 2 23311201354 ENDED Shop at ECS Tuning
11 Selector rod 1 23311201365 ENDED Shop at ECS Tuning
12 Shifting fork 1st and reverse gear 1 23311201351 ENDED Shop at ECS Tuning
1. u. 2. Gang -> Getr.Nr. 23275
3. u. 4. Gang -> Getr.Nr. 32926
13 Insert 4 23311201342 ENDED Shop at ECS Tuning
1. u. 2. Gang Getr.Nr. 23276 ->
3. u. 4. Gang Getr.Nr. 32927 ->
13 Insert 4 23311202888 ENDED Shop at ECS Tuning
Notes
  • ENDED = the part has been discontinued (no longer available).
