Getrag 262 housing+attaching parts for BMW 2.5CS-3.0CSL 2.5CS
This Getrag 262 housing+attaching parts technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 2.5CS. It includes part names, part numbers and all associated mounting hardware.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Gearshift rod joint | 1 | 23411466130 | $51.66 | ENDED | Shop at ECS Tuning | ||||
| 01 | Gearshift rod joint | 1 | 25111205070 | ENDED | Shop at ECS Tuning | |||||
| 01 | Gearshift rod joint | SCHWARZ | 1 | 25117503525 | $37.51 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Straight selector rod | L=151MM | 1 | 25111206888 | $27.51 | Shop at ECS Tuning | ||||
| -- | Shim | 16X10,2X0,65 | 4 | 25111220199 | $0.30 | Shop at ECS Tuning | ||||
| -- | Shift lever-lower part | 1 | 25111220213 | $23.00 | Shop at ECS Tuning | |||||
| 02 | Plastic washer | 1 | 25111434194 | $0.85 | Shop at ECS Tuning | |||||
| 03 | Tension bush | 1 | 23411466132 | $12.47 | Shop at ECS Tuning | |||||
| 03 | Sleeve | 1 | 25111203132 | $4.88 | ENDED | Shop at ECS Tuning | ||||
| 04 | Wave washer | 8,4X15-ZNS3 | 6 | 07119904115 | $0.09 | Shop at ECS Tuning | ||||
| 05 | Hex bolt | M8X30-ZN | 4 | 07119913662 | $0.22 | Shop at ECS Tuning | ||||
| 06 | Shifting arm | 1 | 25111205384 | $50.29 | ENDED | Shop at ECS Tuning | ||||
| 07 | Washer | 1 | 23411466119 | $0.14 | ENDED | Shop at ECS Tuning | ||||
| 09 | Lock Ring | 1 | 04/1971 | 11/1975 | 23411466112 | $0.68 | Shop at ECS Tuning | |||
| 10 | Spacer sleeve | 1 | 23411200844 | $2.27 | Shop at ECS Tuning | |||||
| 11 | Compression spring | 1 | 23411200845 | $1.33 | Shop at ECS Tuning | |||||
| 12 | Ball Cup upper | 2 | 23411466110 | $8.01 | Shop at ECS Tuning | |||||
| 14 | Straight selector rod | 1 | 04/1971 | 11/1975 | 25111204364 | $30.59 | Shop at ECS Tuning | |||
| 16 | Dowel pin | 1 | 23411466134 | $0.70 | Shop at ECS Tuning | |||||
| 17 | Supporting bracket | 4 | 25111202842 | $20.64 | Shop at ECS Tuning | |||||
| 18 | Hex bolt | M8X40-ZNNIV SI | 4 | 07119905549 | $1.05 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
