Manual Transmission S5D...Z for BMW 5 Series E34 530i (1996)
This Manual Transmission S5D...Z technical drawing provides a detailed breakdown of the assembly for the 5 Series E34 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | RP 5-speed transmission | S5D 320Z - THDY | 1 | 23001222997 | $2851.38 | +core | Shop at ECS Tuning | |||
| 02 | Stick-on label, transmission oil | ATF-OIL | 1 | 23111228008 | $1.37 | ENDED | Shop at ECS Tuning | |||
| 03 | Gasket set | S5D...Z | 1 | 23111224925 | $41.43 | Shop at ECS Tuning | ||||
| 04 | Stick-on label, transmission oil | MTF-LT-2 | 1 | 23007533514 | $1.62 | Shop at ECS Tuning |
Notes
- +core = plus core charge (possibility of a return of the old part)
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E34 530i Manual Transmission S5D...Z?
- This technical diagram illustrates the Manual Transmission S5D...Z within the Manual Transmission group for the 5 Series E34 530i produced during 1996. It provides a detailed exploded view of the components, identifying key parts such as the RP 5-speed transmission (Part #23001222997).
- Which models use the hardware listed in this Manual Transmission S5D...Z?
- The hardware and components featured in the Manual Transmission S5D...Z are specific to the 5 Series E34 530i produced during 1996. These technical specifications ensure that parts like the RP 5-speed transmission (23001222997) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Manual Transmission S5D...Z assembly?
- Each item in the Manual Transmission S5D...Z corresponds to the numbered list below the illustration. For the 5 Series E34 530i, you can identify the RP 5-speed transmission by locating its position on the schematic, which then links to the official BMW part number 23001222997 for the Manual Transmission section.
