GA8HP90Z Shift shaft for BMW 7 Series F02 760Li
This GA8HP90Z Shift shaft technical drawing provides a detailed breakdown of the assembly for the 7 Series F02 760Li. It includes part names, part numbers and all associated mounting hardware.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Repair kit selector rod | 1 | 09/2010 | 24507613240 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Screw plug | M18X1,5 | 1 | 09/2010 | 07145A7A846 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series F02 760Li GA8HP90Z Shift shaft?
- This technical diagram illustrates the GA8HP90Z Shift shaft within the Automatic transmission group for the 7 Series F02 760Li. It provides a detailed exploded view of the components, identifying key parts such as the Repair kit selector rod (Part #24507613240).
- Which models use the hardware listed in this GA8HP90Z Shift shaft?
- The hardware and components featured in the GA8HP90Z Shift shaft are specific to the 7 Series F02 760Li. These technical specifications ensure that parts like the Repair kit selector rod (24507613240) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the GA8HP90Z Shift shaft assembly?
- Each item in the GA8HP90Z Shift shaft corresponds to the numbered list below the illustration. For the 7 Series F02 760Li, you can identify the Repair kit selector rod by locating its position on the schematic, which then links to the official BMW part number 24507613240 for the Automatic transmission section.
