GA8HP50Z selector shaft for BMW 7 Series G12 725Ld (2017)
This GA8HP50Z selector shaft technical drawing provides a detailed breakdown of the assembly for the 7 Series G12 725Ld. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2017.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Repair kit selector rod | 1 | 01/2021 | 24505A131C2 | Shop at ECS Tuning | |||||
| 01 | Repair kit selector rod | 1 | 24505A131C3 | Shop at ECS Tuning | ||||||
| 02 | Screw plug | M18X1,5 | 1 | 07145A7A846 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series G12 725Ld GA8HP50Z selector shaft?
- This technical diagram illustrates the GA8HP50Z selector shaft within the Automatic transmission group for the 7 Series G12 725Ld produced during 2017. It provides a detailed exploded view of the components, identifying key parts such as the Repair kit selector rod (Part #24505A131C2).
- Which models use the hardware listed in this GA8HP50Z selector shaft?
- The hardware and components featured in the GA8HP50Z selector shaft are specific to the 7 Series G12 725Ld produced during 2017. These technical specifications ensure that parts like the Repair kit selector rod (24505A131C2) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the GA8HP50Z selector shaft assembly?
- Each item in the GA8HP50Z selector shaft corresponds to the numbered list below the illustration. For the 7 Series G12 725Ld, you can identify the Repair kit selector rod by locating its position on the schematic, which then links to the official BMW part number 24505A131C2 for the Automatic transmission section.
