GA8HP51X electric oil pump for BMW 5 Series G30 540iX (2020)
This GA8HP51X electric oil pump technical drawing provides a detailed breakdown of the assembly for the 5 Series G30 540iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2020.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Repair kit for electric oil pump | GA8HP51X | 1 | 02/2025 | 24348743465 | Shop at ECS Tuning | ||||
| 01 | Repair kit for electric oil pump | GA8HP51X | 1 | 24345B79206 | Shop at ECS Tuning | |||||
| 02 | Screw plug | M18X1,5 | 1 | 07145A7A846 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series G30 540iX GA8HP51X electric oil pump?
- This technical diagram illustrates the GA8HP51X electric oil pump within the Automatic transmission group for the 5 Series G30 540iX produced during 2020. It provides a detailed exploded view of the components, identifying key parts such as the Repair kit for electric oil pump (Part #24348743465).
- Which models use the hardware listed in this GA8HP51X electric oil pump?
- The hardware and components featured in the GA8HP51X electric oil pump are specific to the 5 Series G30 540iX produced during 2020. These technical specifications ensure that parts like the Repair kit for electric oil pump (24348743465) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the GA8HP51X electric oil pump assembly?
- Each item in the GA8HP51X electric oil pump corresponds to the numbered list below the illustration. For the 5 Series G30 540iX, you can identify the Repair kit for electric oil pump by locating its position on the schematic, which then links to the official BMW part number 24348743465 for the Automatic transmission section.
