Drive shaft (swivel joint) for BMW 3 Series E46 318i (2003)
This Drive shaft (swivel joint) technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 318i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Manual drive shaft transmission | L=1639MM | 1 | 26107519293 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Butyl tape, Ködiplast HV 578-59 | 190X20X8MM | 1 | 83225A1B482 | Shop at ECS Tuning | |||||
| DRIVE SHAFT HALF REAR D=60mm |
||||||||||
| -- | Compensating plate | H=2MM | 2 | 26121229539 | $1.77 | Shop at ECS Tuning | ||||
| DRIVE SHAFT HALF REAR D=60mm |
||||||||||
| For vehicles with Automatic transmission |
S205A=Yes |
|||||||||
| 01 | Drive shaft automatic transmission | L=1427MM | 1 | 26117519303 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Butyl tape, Ködiplast HV 578-59 | 190X20X8MM | 1 | 83225A1B482 | Shop at ECS Tuning | |||||
| DRIVE SHAFT HALF REAR D=60mm |
||||||||||
