Driveshaft / recessed nut for BMW 1 Series F21 LCI 125i (2016)
This Driveshaft / recessed nut technical drawing provides a detailed breakdown of the assembly for the 1 Series F21 LCI 125i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2016.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Important! Note Repair Manual |
||||||||||
| 01 | Manual drive shaft transmission | L=1505MM | 1 | 26107598375 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Repair kit recessed nut blue | M39X1,5X20 | 1 | 33127607158 | Shop at ECS Tuning | |||||
| For vehicles with Automatic transmission or Sport automatic transmission Important! Note Repair Manual |
S205A=Yes S2TBA=Yes |
|||||||||
| 02 | Drive shaft automatic transmission | L=1419MM | 1 | 26107598383 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Repair kit recessed nut blue | M39X1,5X20 | 1 | 33127607158 | Shop at ECS Tuning | |||||
| Important! Note Repair Manual Replace bolts on transmission! |
||||||||||
| 03 | Repair kit recessed nut blue | M39X1,5X20 | 1 | 33127607158 | Shop at ECS Tuning | |||||
