Oil filter kit, double clutch transmiss for BMW 3 Series E93 335i (2010)
This Oil filter kit, double clutch transmiss technical drawing provides a detailed breakdown of the assembly for the 3 Series E93 335i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2010.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| VALUE REPAIR PARTS! Everything in one click! Contains all separate components for oil change! Improves the repair quality. Reduced wear! Extends the service life of the transmission! Increases driving comfort! |
||||||||||
| 01 | Oil filter kit, double clutch transmiss | 1 | 28005B43146 | Shop at ECS Tuning | ||||||
| Please observe Repair Manual. | ||||||||||
| 02 | BMW dctf 1+ | 1000ML | X | 83222446673 | Shop at ECS Tuning | |||||
| Important! It is vital to observe the oil balancing procedure described in the repair instructions. The required oil quantity can vary! |
||||||||||
