Front spring strut/shock absorber for BMW 7 Series E38 728iL (1998)
This Front spring strut/shock absorber technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 728iL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Left front spring strut | 1 | 31311091569 | $382.20 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| 01 | Front right spring strut | 1 | 31311091570 | $382.20 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| -- | Self-locking hex nut | M14X1,5-05 ZNS3 | 1 | 31106774714 | $1.12 | Shop at ECS Tuning | ||||
| -- | Hex bolt with washer | M12X1,5X55-10.9 | 1 | 31306779487 | $2.17 | Shop at ECS Tuning | ||||
| For vehicles with Electronic Damper Control (EDC) |
S223A=Yes |
|||||||||
| 01 | Left front spring strut | EDC | 1 | 31311091557 | $1009.39 | Shop at ECS Tuning | ||||
| Required for repair | ||||||||||
| 01 | Front right spring strut | EDC | 1 | 31311091558 | $1009.39 | Shop at ECS Tuning | ||||
| Required for repair | ||||||||||
| -- | Self-locking hex nut | M14X1,5-05 ZNS3 | 1 | 31106774714 | $1.12 | Shop at ECS Tuning | ||||
| -- | Hex bolt with washer | M12X1,5X55-10.9 | 1 | 31306779487 | $2.17 | Shop at ECS Tuning | ||||
| For vehicles with National version eastern europe or Poor road package |
L816A=Yes S815A=Yes |
|||||||||
| 01 | Left front spring strut | 1 | 31311091925 | $421.02 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| 01 | Front right spring strut | 1 | 31311091926 | $421.02 | Shop at ECS Tuning | |||||
| Required for repair | ||||||||||
| -- | Self-locking hex nut | M14X1,5-05 ZNS3 | 1 | 31106774714 | $1.12 | Shop at ECS Tuning | ||||
| -- | Hex bolt with washer | M12X1,5X55-10.9 | 1 | 31306779487 | $2.17 | Shop at ECS Tuning | ||||
| 02 | King pin left | 1 | 31211142085 | $271.80 | +core | Shop at ECS Tuning | ||||
| 02 | King pin right | 1 | 31211142086 | $271.80 | +core | Shop at ECS Tuning | ||||
| 03 | Hex bolt with washer | M12X1,5X55-10.9 | 2 | 31306779487 | $2.17 | Shop at ECS Tuning | ||||
| 04 | Pulse generator, ABS | 2 | 09/1998 | 34521182076 | $129.58 | Shop at ECS Tuning | ||||
| 06 | Left ABS/BVA tube bracket | 1 | 31181182257 | $1.83 | Shop at ECS Tuning | |||||
| 06 | Right ABS/BVA tube bracket | 1 | 31181182258 | $1.83 | Shop at ECS Tuning | |||||
Notes
- +core = plus core charge (possibility of a return of the old part)
