Front spring strut/shock absorber for BMW 2.5CS-3.0CSL 3.0CSL (1973)
This Front spring strut/shock absorber technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 3.0CSL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Stabilizer | D=17MM | 1 | 12/1968 | 11/1975 | 31351103000 | ENDED | Shop at ECS Tuning | ||
| only in conjunction with "Städtepaket" | ||||||||||
| 02 | Bracket front | 29 MM | 2 | 12/1968 | 11/1975 | 31351101107 | ENDED | Shop at ECS Tuning | ||
| only in conjunction with "Städtepaket" | ||||||||||
| 02 | Bracket front | 25 MM | 2 | 12/1968 | 11/1975 | 31351113284 | ENDED | Shop at ECS Tuning | ||
| only in conjunction with "Städtepaket" | ||||||||||
| 03 | Wave washer | B10-ZNS3 | 2 | 07119904463 | Shop at ECS Tuning | |||||
| only in conjunction with "Städtepaket" | ||||||||||
| 04 | Hex nut | M10-8-ZNS | 2 | 07119915558 | $0.88 | Shop at ECS Tuning | ||||
| only in conjunction with "Städtepaket" | ||||||||||
| 05 | Hex bolt | M8X160 | 2 | 07119912595 | $3.47 | Shop at ECS Tuning | ||||
| only in conjunction with "Städtepaket" | ||||||||||
| 06 | Plate | 8 | 31351114570 | $3.59 | Shop at ECS Tuning | |||||
| only in conjunction with "Städtepaket" | ||||||||||
| 07 | Rubber Ring | 8 | 31351125712 | $1.37 | Shop at ECS Tuning | |||||
| only in conjunction with "Städtepaket" | ||||||||||
| 08 | Spacer sleeve | 2 | 31352654108 | $4.68 | ENDED | Shop at ECS Tuning | ||||
| 09 | Hex nut | M8-8-ZNS3 | 4 | 11/1975 | 07119904032 | $0.16 | Shop at ECS Tuning | |||
| only in conjunction with "Städtepaket" | ||||||||||
| 09 | Hex nut | M8-8-ZNNIV SI | 4 | 07119905515 | $0.16 | Shop at ECS Tuning | ||||
| only in conjunction with "Städtepaket" | ||||||||||
| 10 | Fillister-head screw | M10X22 | 2 | 07119901979 | $1.98 | Shop at ECS Tuning | ||||
| only in conjunction with "Städtepaket" | ||||||||||
| 11 | Rubber Mounting | D=17MM | 2 | 12/1968 | 11/1975 | 31352654110 | $19.85 | Shop at ECS Tuning | ||
| only in conjunction with "Städtepaket" | ||||||||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2.5CS-3.0CSL 3.0CSL Front spring strut/shock absorber?
- This technical diagram illustrates the Front spring strut/shock absorber within the Front Axle group for the 2.5CS-3.0CSL 3.0CSL produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Stabilizer (Part #31351103000).
- Which models use the hardware listed in this Front spring strut/shock absorber?
- The hardware and components featured in the Front spring strut/shock absorber are specific to the 2.5CS-3.0CSL 3.0CSL produced during 1973. These technical specifications ensure that parts like the Stabilizer (31351103000) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Front spring strut/shock absorber assembly?
- Each item in the Front spring strut/shock absorber corresponds to the numbered list below the illustration. For the 2.5CS-3.0CSL 3.0CSL, you can identify the Stabilizer by locating its position on the schematic, which then links to the official BMW part number 31351103000 for the Front Axle section.
