Oil carrier / Single parts for BMW 5 Series E28 520i (1982)
This Oil carrier / Single parts technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 520i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1982.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| 02 | Cover | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| 03 | Gasket ring | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 04 | Clamp | 1 | 32411124719 | $5.14 | ENDED | Shop at ECS Tuning | ||||
| 05 | Spring washer Black | B6-ZN | 1 | 06/1988 | 07119932073 | $0.38 | Shop at ECS Tuning | |||
| 05 | Washer | 5.3-140 HV-ZNS | 1 | 07119936439 | $0.40 | Shop at ECS Tuning | ||||
| 06 | Hex bolt | M6X16-8.8-ZNS3 | 1 | 07119904357 | $0.36 | Shop at ECS Tuning | ||||
| 07 | Hex head screw | ST6,3X19-C-Z1 | 2 | 07119916970 | $0.30 | Shop at ECS Tuning | ||||
| 08 | Body nut | B6,3-6 | 2 | 16111152613 | $0.35 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
