Oil carrier / Single parts for BMW 5 Series E34 530i (1995)
This Oil carrier / Single parts technical drawing provides a detailed breakdown of the assembly for the 5 Series E34 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1995.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| For vehicles with Self-levelling suspension |
=Yes |
|||||||||
| 02 | Oil carrier | ZF | 1 | 32411139024 | $336.53 | Shop at ECS Tuning | ||||
| 03 | Cover | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| 04 | Gasket ring | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 05 | Clamp | 1 | 32411133983 | $10.17 | Shop at ECS Tuning | |||||
| 06 | Washer | 5.3-140 HV-ZNS | 1 | 07119936439 | $0.40 | Shop at ECS Tuning | ||||
| 07 | Hex bolt | M6X16-8.8-ZNS3 | 1 | 07119904357 | $0.36 | Shop at ECS Tuning | ||||
| 08 | Self-locking hex nut | M6-10 ZN | 2 | 12/1995 | 07129922705 | $0.27 | ENDED | Shop at ECS Tuning | ||
| 08 | Self-locking hex nut | M6 ZNNIV SI | 2 | 07147575163 | $0.25 | Shop at ECS Tuning | ||||
| 09 | Self-locking hex nut | M6-10 ZN | 2 | 01/1996 | 07129922705 | $0.27 | ENDED | Shop at ECS Tuning | ||
| 09 | Self-locking hex nut | M6 ZNNIV SI | 2 | 07147575163 | $0.25 | Shop at ECS Tuning | ||||
| 11 | Washer | 6,4X25X1,5 | 2 | 07146977329 | $0.64 | Shop at ECS Tuning | ||||
| 12 | Spacer bush | 12MM | 2 | 37211119062 | $3.37 | Shop at ECS Tuning | ||||
| 13 | Rubber grommet | 2 | 37211119643 | $1.45 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
