Oil carrier / Single parts for BMW 7 Series E38 728i (1998)
This Oil carrier / Single parts technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 728i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1998.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Label, oil container-power steering pump | ATF | 1 | 71246798132 | Shop at ECS Tuning | |||||
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Label, oil container-power steering pump | ATF | 1 | 71246798132 | Shop at ECS Tuning | |||||
| For vehicles with Self-levelling suspension |
S220A=Yes |
|||||||||
| 01 | Oil carrier | V=1,1 LTR. | 1 | 32411092111 | $64.02 | ENDED | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | Label, oil container-power steering pump | ATF | 1 | 71246798132 | Shop at ECS Tuning | |||||
| 02 | Cover | 1 | 32411092649 | $16.03 | Shop at ECS Tuning | |||||
| 02 | Cover | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| For vehicles with Self-levelling suspension |
S220A=Yes |
|||||||||
| 02 | Cover | 1 | 32411092649 | $16.03 | Shop at ECS Tuning | |||||
| 03 | Gasket ring | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 04 | Bracket, oil carrier | 1 | 32411092940 | $8.52 | Shop at ECS Tuning | |||||
| 05 | Hex bolt with washer | M6X16-U1-8.8 | 1 | 07119904524 | $0.25 | Shop at ECS Tuning | ||||
| 06 | Rubber grommet | 2 | 11421742593 | $1.05 | Shop at ECS Tuning | |||||
| For vehicles with Self-levelling suspension |
S220A=Yes |
|||||||||
| 06 | Rubber Mounting | 1 | 13711427713 | Shop at ECS Tuning | ||||||
| 07 | Sleeve | 2 | 32411095937 | $1.68 | Shop at ECS Tuning | |||||
| 08 | Washer | 6,4X25X1,5 | 2 | 07146977329 | $0.64 | Shop at ECS Tuning | ||||
| 09 | Hex bolt with washer | M8X18-U1-8.8 | 2 | 07119905529 | $0.96 | Shop at ECS Tuning | ||||
| 09 | Hex nut with plate | M6-8-ZNNIV SI | 2 | 07119905949 | $0.24 | Shop at ECS Tuning | ||||
| For vehicles with Self-levelling suspension |
S220A=Yes |
|||||||||
| 14 | Oil carrier | V=1,1 LTR. | 1 | 32411092111 | $64.02 | ENDED | Shop at ECS Tuning | |||
| 15 | Cover | 1 | 32411092649 | $16.03 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
