Oil carrier / Single parts for BMW 7 Series E66 735Li (2004)
This Oil carrier / Single parts technical drawing provides a detailed breakdown of the assembly for the 7 Series E66 735Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2004.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Dynamic Drive |
S229A=No |
|||||||||
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Label, oil container-power steering pump | ATF | 1 | 71246798132 | Shop at ECS Tuning | |||||
| 02 | Cover | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Label, oil container-power steering pump | ATF | 1 | 71246798132 | Shop at ECS Tuning | |||||
| 03 | Gasket ring | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 04 | Bracket, oil carrier | 1 | 32411094917 | $6.42 | Shop at ECS Tuning | |||||
| 05 | Hex bolt with washer | M6X16-U1-8.8 | 1 | 07119904524 | $0.25 | Shop at ECS Tuning | ||||
| 06 | Rubber Mounting | 2 | 34511162818 | $2.57 | Shop at ECS Tuning | |||||
| 07 | Spacer sleeve | ZNS3 | 2 | 07146977328 | $1.21 | Shop at ECS Tuning | ||||
| 08 | Hex nut | M6-8-ZNS3 | 2 | 07119905128 | $0.44 | Shop at ECS Tuning | ||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series E66 735Li Oil carrier / Single parts?
- This technical diagram illustrates the Oil carrier / Single parts within the Steering group for the 7 Series E66 735Li produced during 2004. It provides a detailed exploded view of the components, identifying key parts such as the Oil carrier (Part #32416851217).
- Which models use the hardware listed in this Oil carrier / Single parts?
- The hardware and components featured in the Oil carrier / Single parts are specific to the 7 Series E66 735Li produced during 2004. These technical specifications ensure that parts like the Oil carrier (32416851217) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Oil carrier / Single parts assembly?
- Each item in the Oil carrier / Single parts corresponds to the numbered list below the illustration. For the 7 Series E66 735Li, you can identify the Oil carrier by locating its position on the schematic, which then links to the official BMW part number 32416851217 for the Steering section.
