Oil carrier / Single parts for BMW 3 Series E30 320i (1991)
This Oil carrier / Single parts technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1991.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Oil carrier | CHF 11.S | 1 | 32416851217 | Shop at ECS Tuning | |||||
| 02 | Cover | CHF 11.S | 1 | 32416851332 | Shop at ECS Tuning | |||||
| 03 | Gasket ring | 1 | 32411128333 | $2.38 | Shop at ECS Tuning | |||||
| 04 | Holder | 1 | 32411126321 | $6.84 | Shop at ECS Tuning | |||||
| 05 | Hex bolt | M6X16-8.8-ZNS3 | 2 | 07119904357 | $0.36 | Shop at ECS Tuning | ||||
| 06 | Washer | 5.3-140 HV-ZNS | 1 | 07119936439 | $0.40 | Shop at ECS Tuning | ||||
| 07 | Spring washer | B6 | 1 | 07119933082 | $0.09 | Shop at ECS Tuning | ||||
| 08 | C-clip nut | M6 | 1 | 07147151144 | $0.74 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 320i Oil carrier / Single parts?
- This technical diagram illustrates the Oil carrier / Single parts within the Steering group for the 3 Series E30 320i produced during 1991. It provides a detailed exploded view of the components, identifying key parts such as the Oil carrier (Part #32416851217).
- Which models use the hardware listed in this Oil carrier / Single parts?
- The hardware and components featured in the Oil carrier / Single parts are specific to the 3 Series E30 320i produced during 1991. These technical specifications ensure that parts like the Oil carrier (32416851217) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Oil carrier / Single parts assembly?
- Each item in the Oil carrier / Single parts corresponds to the numbered list below the illustration. For the 3 Series E30 320i, you can identify the Oil carrier by locating its position on the schematic, which then links to the official BMW part number 32416851217 for the Steering section.
