hydraulic pump for BMW 6 Series F12 LCI 640i (2018)
This hydraulic pump technical drawing provides a detailed breakdown of the assembly for the 6 Series F12 LCI 640i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2018.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Dynamic Drive or Chassis & suspens. setup"Adaptive Drive" |
S229A=Yes S2VAA=Yes |
||||||||
| For vehicles with Chassis & suspens. setup"Adaptive Drive" |
S2VAA=Yes |
|||||||||
| 01 | hydraulic pump | DYNAMIC DRIVE | 1 | 07/2012 | 32416850590 | +core | Shop at ECS Tuning | |||
| 02 | Pulley | 1 | 07/2012 | 32427582943 | Shop at ECS Tuning | |||||
| 03 | Hex bolt with washer | M8X14-10.9 | 3 | 07/2012 | 32427574840 | $0.62 | Shop at ECS Tuning | |||
| 04 | ASA-Bolt | M10X35 | 2 | 07/2012 | 22116769558 | $0.83 | Shop at ECS Tuning | |||
| 05 | ASA-Bolt | M10X35 | 1 | 07/2012 | 22116769558 | $0.83 | Shop at ECS Tuning | |||
Notes
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 6 Series F12 LCI 640i hydraulic pump?
- This technical diagram illustrates the hydraulic pump within the Steering group for the 6 Series F12 LCI 640i produced during 2018. It provides a detailed exploded view of the components, identifying key parts such as the hydraulic pump (Part #32416850590).
- Which models use the hardware listed in this hydraulic pump?
- The hardware and components featured in the hydraulic pump are specific to the 6 Series F12 LCI 640i produced during 2018. These technical specifications ensure that parts like the hydraulic pump (32416850590) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the hydraulic pump assembly?
- Each item in the hydraulic pump corresponds to the numbered list below the illustration. For the 6 Series F12 LCI 640i, you can identify the hydraulic pump by locating its position on the schematic, which then links to the official BMW part number 32416850590 for the Steering section.
