Power steering pump for BMW 8 Series E31 840i (1996)
This Power steering pump technical drawing provides a detailed breakdown of the assembly for the 8 Series E31 840i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vane pump | 1 | 09/1993 | 32411141568 | $910.99 | +core | Shop at ECS Tuning | |||
| 02 | Pulley | D=105MM | 1 | 09/1993 | 32421736934 | $31.68 | Shop at ECS Tuning | |||
| 03 | Hex bolt with washer | M8X18-U1-8.8 | 3 | 09/1993 | 07119905529 | $0.96 | Shop at ECS Tuning | |||
| 04 | Hex bolt with washer | M8X30-Z3 | 1 | 09/1993 | 07119915085 | $0.62 | Shop at ECS Tuning | |||
| 05 | Collar nut | M8-8-SC-ZNNIV | 3 | 09/1993 | 07119906089 | $0.32 | Shop at ECS Tuning | |||
| 06 | Threaded bolt | M8X144 | 1 | 09/1993 | 32421747289 | $5.58 | Shop at ECS Tuning |
Notes
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 8 Series E31 840i Power steering pump?
- This technical diagram illustrates the Power steering pump within the Steering group for the 8 Series E31 840i produced during 1996. It provides a detailed exploded view of the components, identifying key parts such as the Vane pump (Part #32411141568).
- Which models use the hardware listed in this Power steering pump?
- The hardware and components featured in the Power steering pump are specific to the 8 Series E31 840i produced during 1996. These technical specifications ensure that parts like the Vane pump (32411141568) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Power steering pump assembly?
- Each item in the Power steering pump corresponds to the numbered list below the illustration. For the 8 Series E31 840i, you can identify the Vane pump by locating its position on the schematic, which then links to the official BMW part number 32411141568 for the Steering section.
