JCW steering wheel for BMW MINI Countryman F60 LCI Cooper (2024)
This JCW steering wheel technical drawing provides a detailed breakdown of the assembly for the MINI Countryman F60 LCI Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Sport automatic transmission and Sport transmission w/ dual-plate clutch and Steering wheel leather Nappa |
S2TBA=No S2TCA=No S2XDA=Yes |
||||||||
| For vehicles with Steering wheel heater Including vehicle wiring harness |
S248A=No |
|||||||||
| 01 | Sport steering wheel, leather | 1 | 03/2021 | 32305A0C814 | Shop at ECS Tuning | |||||
| For vehicles with Steering wheel heater Including vehicle wiring harness |
S248A=Yes |
|||||||||
| 01 | Sport steering wheel, leather | 1 | 03/2021 | 32305A0C815 | Shop at ECS Tuning | |||||
| For vehicles with Steering wheel heater |
S248A=No |
|||||||||
| 02 | connecting line, steering wheel | 1 | 32306864895 | Shop at ECS Tuning | ||||||
| For vehicles with Steering wheel heater |
S248A=Yes |
|||||||||
| 02 | Connecting line steering wheel | 1 | 32305A32949 | Shop at ECS Tuning | ||||||
| For vehicles with UNTAMED EDITION |
P7ENA=Yes |
|||||||||
| 03 | Sports steering wheel trim lower | UNTAMED | 1 | 03/2022 | 32305A1D708 | Shop at ECS Tuning | ||||
| For vehicles with YOUNIQUE TRIM and MINI Cooper Untold Edition and John Cooper Works Trim |
P7EBA=No P7GVA=No P7KQA=Yes |
|||||||||
| 03 | Cover f sports steering wheel, bottom | JCW | 1 | 03/2021 | 32307911388 | Shop at ECS Tuning | ||||
| For vehicles with YOUNIQUE TRIM and MINI Cooper Untold Edition and John Cooper Works Trim |
P7EBA=Yes P7GVA=No P7KQA=No |
|||||||||
| 03 | Cover f sports steering wheel, bottom | MINI YOURS | 1 | 03/2021 | 32307911390 | Shop at ECS Tuning | ||||
| For vehicles with YOUNIQUE TRIM and UNTAMED EDITION and MINI Cooper Untold Edition and John Cooper Works Trim |
P7EBA=No P7ENA=No P7GVA=No P7KQA=No |
|||||||||
| 03 | Cover f sports steering wheel, bottom | PIANO BLACK | 1 | 03/2021 | 32305A078C3 | Shop at ECS Tuning | ||||
| 04 | Cover for steering wheel, rear | 1 | 03/2021 | 32305A0C811 | Shop at ECS Tuning | |||||
| 05 | Screw for thermoplastic plastics | TS4X17 TORX T25 | 2 | 61319318951 | Shop at ECS Tuning | |||||
| 06 | Torx screw, micro-encapsulated | M14X1.5X25 ZNS3 | 1 | 07149890645 | Shop at ECS Tuning | |||||
| 07 | Airbag unit sports steer.wheel DS | 1 | 32309462208 | Shop at ECS Tuning | ||||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW MINI Countryman F60 LCI Cooper JCW steering wheel?
- This technical diagram illustrates the JCW steering wheel within the Steering group for the MINI Countryman F60 LCI Cooper produced during 2024. It provides a detailed exploded view of the components, identifying key parts such as the Sport steering wheel, leather (Part #32305A0C814).
- Which models use the hardware listed in this JCW steering wheel?
- The hardware and components featured in the JCW steering wheel are specific to the MINI Countryman F60 LCI Cooper produced during 2024. These technical specifications ensure that parts like the Sport steering wheel, leather (32305A0C814) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the JCW steering wheel assembly?
- Each item in the JCW steering wheel corresponds to the numbered list below the illustration. For the MINI Countryman F60 LCI Cooper, you can identify the Sport steering wheel, leather by locating its position on the schematic, which then links to the official BMW part number 32305A0C814 for the Steering section.
