Differential-oil carrier for BMW 6 Series E24 635CSi (1978)
This Differential-oil carrier technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 635CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1978.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Oil carrier | 1 | 05/1982 | 33111207631 | $129.46 | ENDED | Shop at ECS Tuning | |||
| 02 | O-ring | 1 | 05/1982 | 33111207395 | $1.40 | ENDED | Shop at ECS Tuning | |||
| 03 | Vent cap | 1 | 05/1982 | 33111202497 | $17.23 | Shop at ECS Tuning | ||||
| 04 | Gasket ring | A22X27-AL | 2 | 05/1982 | 07119963355 | $0.36 | Shop at ECS Tuning | |||
| 05 | Threaded pipe joint | 1 | 05/1982 | 33111207398 | $5.02 | Shop at ECS Tuning | ||||
| 06 | Slip ring | L8 | 1 | 05/1982 | 07119970110 | ENDED | Shop at ECS Tuning | |||
| 07 | Cap nut | AL8 | 1 | 05/1982 | 07119970258 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
