Suspension for trailer hitch for BMW 5 Series E28 524d (1987)
This Suspension for trailer hitch technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 524d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1987.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Coil spring | 2 | 33531126901 | ENDED | Shop at ECS Tuning | |||||
| 02 | Shock absorber, rear | 2 | 33521125770 | $227.66 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E28 524d Suspension for trailer hitch?
- This technical diagram illustrates the Suspension for trailer hitch within the Rear Axle group for the 5 Series E28 524d produced during 1987. It provides a detailed exploded view of the components, identifying key parts such as the Coil spring (Part #33531126901).
- Which models use the hardware listed in this Suspension for trailer hitch?
- The hardware and components featured in the Suspension for trailer hitch are specific to the 5 Series E28 524d produced during 1987. These technical specifications ensure that parts like the Coil spring (33531126901) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Suspension for trailer hitch assembly?
- Each item in the Suspension for trailer hitch corresponds to the numbered list below the illustration. For the 5 Series E28 524d, you can identify the Coil spring by locating its position on the schematic, which then links to the official BMW part number 33531126901 for the Rear Axle section.
