Rear-axle-drive parts for BMW 2.5CS-3.0CSL 3.0CSL (1973)
This Rear-axle-drive parts technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 3.0CSL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Housing | 1 | 33113704100 | $341.50 | ENDED | Shop at ECS Tuning | ||||
| 02 | Screw plug with O-ring | M22X1,5-ZNS3 | 2 | 33117525064 | $3.91 | Shop at ECS Tuning | ||||
| 03 | Gasket ring | A22X27-AL | 2 | 07119963355 | $0.36 | Shop at ECS Tuning | ||||
| 04 | Hex bolt | M12X1,5X25 | 8 | 07119911694 | $0.82 | Shop at ECS Tuning | ||||
| 05 | Washer | A8 | 8 | 33173628125 | $0.95 | ENDED | Shop at ECS Tuning | |||
| 07 | Vent cap | 1 | 33111202497 | $17.23 | Shop at ECS Tuning | |||||
| 08 | Hex bolt | M6X16-8.8-ZNS3 | 4 | 07119904357 | $0.36 | Shop at ECS Tuning | ||||
| 09 | Wave washer | B6 | 4 | 07119932072 | $0.09 | ENDED | Shop at ECS Tuning | |||
| 10 | Gasket Asbestos Free | 1 | 33113404142 | $8.18 | Shop at ECS Tuning | |||||
| 11 | Cover | 1 | 33111202624 | $19.67 | ENDED | Shop at ECS Tuning | ||||
| 12 | Rubber Mounting | RUND | 1 | 33171126951 | $86.07 | Shop at ECS Tuning | ||||
| 13 | Wave washer | B10-ZNS3 | 4 | 07119904463 | Shop at ECS Tuning | |||||
| 14 | Hex bolt | M10X18-8.8-ZNS3 | 4 | 07119904033 | $0.65 | Shop at ECS Tuning | ||||
| 15 | Washer | 13X30X4MM | 1 | 33171125439 | $0.73 | Shop at ECS Tuning | ||||
| 16 | Hex bolt | M12X1,5X85 | 1 | 07119914681 | $2.09 | Shop at ECS Tuning | ||||
| 17 | Wave washer | 8,4X15-ZNS3 | 8 | 07119904115 | $0.09 | Shop at ECS Tuning | ||||
| 18 | Hex bolt | M8X25-8.8-ZNNIV | 8 | 07119906181 | $0.55 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2.5CS-3.0CSL 3.0CSL Rear-axle-drive parts?
- This technical diagram illustrates the Rear-axle-drive parts within the Rear Axle group for the 2.5CS-3.0CSL 3.0CSL produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Housing (Part #33113704100).
- Which models use the hardware listed in this Rear-axle-drive parts?
- The hardware and components featured in the Rear-axle-drive parts are specific to the 2.5CS-3.0CSL 3.0CSL produced during 1973. These technical specifications ensure that parts like the Housing (33113704100) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Rear-axle-drive parts assembly?
- Each item in the Rear-axle-drive parts corresponds to the numbered list below the illustration. For the 2.5CS-3.0CSL 3.0CSL, you can identify the Housing by locating its position on the schematic, which then links to the official BMW part number 33113704100 for the Rear Axle section.
