Spring strut, rear for BMW 2500-3.3Li 2500 (1970)
This Spring strut, rear technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 2500. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1970.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Shock absorber, rear | BILSTEIN | 2 | 08/1968 | 02/1977 | 33521114387 | $202.00 | ENDED | Shop at ECS Tuning | |
| 02 | Hex bolt | M14X1,5X70 | 2 | 07119914832 | $2.60 | Shop at ECS Tuning | ||||
| 03 | Rubber Mounting | 2 | 08/1968 | 02/1977 | 33521106228 | ENDED | Shop at ECS Tuning | |||
| 04 | Washer | A15 ZNS3 | 2 | 08/1968 | 02/1977 | 07119905829 | $0.74 | Shop at ECS Tuning | ||
| 05 | Self-locking hex nut | M14X1,5 | 2 | 07129922745 | $1.04 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 2500 Spring strut, rear?
- This technical diagram illustrates the Spring strut, rear within the Rear Axle group for the 2500-3.3Li 2500 produced during 1970. It provides a detailed exploded view of the components, identifying key parts such as the Shock absorber, rear (Part #33521114387).
- Which models use the hardware listed in this Spring strut, rear?
- The hardware and components featured in the Spring strut, rear are specific to the 2500-3.3Li 2500 produced during 1970. These technical specifications ensure that parts like the Shock absorber, rear (33521114387) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Spring strut, rear assembly?
- Each item in the Spring strut, rear corresponds to the numbered list below the illustration. For the 2500-3.3Li 2500, you can identify the Shock absorber, rear by locating its position on the schematic, which then links to the official BMW part number 33521114387 for the Rear Axle section.
