Headlight vertical aim control sensor for BMW 2 Series F74 Gran Coupé 218 (2025)
This Headlight vertical aim control sensor technical drawing provides a detailed breakdown of the assembly for the 2 Series F74 Gran Coupé 218. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Adaptive LED headlight |
S552A=Yes |
||||||||
| 01 | Level sensor | 2 | 37146895466 | Shop at ECS Tuning | ||||||
| 02 | Bracket, level sensor front | 1 | 37146896286 | Shop at ECS Tuning | ||||||
| 03 | Bracket for height sensor, rear | 1 | 37146892286 | Shop at ECS Tuning | ||||||
| 04 | Control rod, front | 1 | 37146892285 | Shop at ECS Tuning | ||||||
| 05 | Control rod, rear | 1 | 37146892287 | Shop at ECS Tuning | ||||||
| 06 | Oval head screw | 4 | 07141543905 | Shop at ECS Tuning | ||||||
| 07 | Hexagon screw, self-threading | M6X16 | 4 | 37146869771 | Shop at ECS Tuning | |||||
| 08 | Prestol-cage | M6 ZNS3 | 1 | 37146850307 | Shop at ECS Tuning | |||||
