Front brake pad wear sensor for BMW 7 Series E32 750i
This Front brake pad wear sensor technical drawing provides a detailed breakdown of the assembly for the 7 Series E32 750i. It includes part names, part numbers and all associated mounting hardware.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with National version Germany |
L801A=Yes |
||||||||
| 01 | Bridgecaliper without brake pads left | 1 | 01/1990 | 34111159775 | $1088.10 | ENDED | Shop at ECS Tuning | |||
| 01 | Bridgecaliper without brake pads right | 1 | 01/1990 | 34111159776 | $1088.10 | ENDED | Shop at ECS Tuning | |||
| 02 | Hex bolt | M12X1,5X41 10.9 | 4 | 01/1990 | 34111151604 | $1.77 | Shop at ECS Tuning | |||
| 03 | Connection pipe | 2 | 01/1990 | 34111160192 | Shop at ECS Tuning | |||||
| 04 | Ventilation valve | M10X1 | 4 | 01/1990 | 34116871581 | Shop at ECS Tuning | ||||
| 05 | Dust cap | 4 | 01/1990 | 34111153198 | $6.15 | Shop at ECS Tuning | ||||
| 06 | Brake pad wear sensor | 1 | 01/1990 | 34351179820 | $17.24 | Shop at ECS Tuning | ||||
| 07 | Cable clamp | D=10-12MM | 1 | 01/1990 | 61131361897 | $0.42 | ENDED | Shop at ECS Tuning | ||
| 08 | Heat resistant plate | D=44MM | 2 | 01/1990 | 34111160193 | ENDED | Shop at ECS Tuning | |||
| 09 | Heat resistant plate | D=40MM | 2 | 01/1990 | 34111160194 | ENDED | Shop at ECS Tuning | |||
| 10 | Repair set brake caliper | ATE | 2 | 01/1990 | 34111160188 | $159.69 | ENDED | Shop at ECS Tuning | ||
| 11 | Set mounting parts | 1 | 01/1990 | 34111160189 | $84.45 | ENDED | Shop at ECS Tuning | |||
| 12 | Repair kit, brake pads asbestos-free | TEXTAR T476 | 1 | 01/1990 | 34111160708 | $127.56 | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| 12 | Repair kit, brake pads asbestos-free | TEXTAR POLITEX | 1 | 01/1990 | 34111160710 | ENDED | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | Brake pad paste | 3G | 1 | 01/1990 | 83192158851 | Shop at ECS Tuning | ||||
| 13 | Brake pad paste | 3G | 1 | 01/1990 | 83192158851 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
