Accelerator pedal for BMW 2500-3.3Li 3.0Si (1977)
This Accelerator pedal technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1977.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 04 | Hex nut | M5-8-ZNNIV SI | 4 | 07119905729 | Shop at ECS Tuning | |||||
| 05 | Ball joint | 4 | 13211260219 | $6.54 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 3.0Si Accelerator pedal?
- This technical diagram illustrates the Accelerator pedal within the Pedals group for the 2500-3.3Li 3.0Si produced during 1977. It provides a detailed exploded view of the components, identifying key parts such as the Hex nut (Part #07119905729).
- Which models use the hardware listed in this Accelerator pedal?
- The hardware and components featured in the Accelerator pedal are specific to the 2500-3.3Li 3.0Si produced during 1977. These technical specifications ensure that parts like the Hex nut (07119905729) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Accelerator pedal assembly?
- Each item in the Accelerator pedal corresponds to the numbered list below the illustration. For the 2500-3.3Li 3.0Si, you can identify the Hex nut by locating its position on the schematic, which then links to the official BMW part number 07119905729 for the Pedals section.
