BMW LA wheel Individual V-Spoke 374-20'' for BMW 6 Series F12 LCI 650iX (2018)
This BMW LA wheel Individual V-Spoke 374-20'' technical drawing provides a detailed breakdown of the assembly for the 6 Series F12 LCI 650iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2018.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Notice: Only for vehicles with EG-BE approval. Official entry in the registration documents may be required for the wheel and tire set under some conditions. Please check vehicle CoC to determine whether an official approval entry for the wheel and tire combination is present. If this is not the case it may be necessary to obtain post-factory field approval sanctioning use in the specific country!! For vehicles with BMW LA wheel Individual V Spoke 374 |
S2NLA=Yes |
||||||||
| 02 | Disk wheel light alloy dekor silver 2 | 8,5JX20 ET:33 | 2 | 36117843717 | Shop at ECS Tuning | |||||
| 02 | Disk wheel, light alloy, in Orbitgrey | 8,5JX20 ET:33 | 2 | 36118091911 | Shop at ECS Tuning | |||||
| only for rear axle Mixed tyres |
||||||||||
| 02 | Disk wheel light alloy dekor silver 2 | 9JX20 ET:44 | 2 | 36117843718 | Shop at ECS Tuning | |||||
| 02 | Disk wheel, light alloy, in Orbitgrey | 9JX20 ET:44 | 2 | 36118091912 | Shop at ECS Tuning | |||||
| 03 | Wheel bolt black | M14X1,25 | 20 | 36136890324 | Shop at ECS Tuning | |||||
| 04 | Hub cap, silver | D=158MM | 4 | 36137849424 | Shop at ECS Tuning | |||||
| 04 | Hub cap orbit grey | D=158MM | 4 | 36138091908 | Shop at ECS Tuning | |||||
| 05 | BMW insignia stamped with adhesive film | D=64,5MM | 4 | 36136767550 | $5.33 | Shop at ECS Tuning | ||||
| 06 | Screw-in valve RDC | 4 | 36146792829 | $13.90 | Shop at ECS Tuning | |||||
| For vehicles with National version Canada |
L838A=Yes |
|||||||||
| 06 | Rubber valve | L=48,5MM | 4 | 36121178869 | $3.30 | Shop at ECS Tuning | ||||
| For vehicles with National version Canada and Tire pressure display |
L838A=Yes S2VBA=Yes |
|||||||||
| 06 | Screw-in valve RDC | 4 | 36146792829 | $13.90 | Shop at ECS Tuning | |||||
| 08 | Valve caps RDC | 4 | 36111095436 | $0.35 | Shop at ECS Tuning | |||||
| For vehicles with National version Canada |
L838A=Yes |
|||||||||
| 08 | Valve caps | 4 | 36121120779 | $0.60 | Shop at ECS Tuning | |||||
| For vehicles with National version Canada and Tire pressure display |
L838A=Yes S2VBA=Yes |
|||||||||
| 08 | Valve caps RDC | 4 | 36111095436 | $0.35 | Shop at ECS Tuning | |||||
| 09 | BMW Individual badge | 4 | 36137897226 | $5.60 | Shop at ECS Tuning | |||||
| 10 | Hub cap puller | 1 | 36132294421 | $9.86 | Shop at ECS Tuning | |||||
