Door weatherstrip front for BMW 3 Series E36 325tds (1999)
This Door weatherstrip front technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 325tds. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1999.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Left roof frame gasket | 1 | 51718233797 | Shop at ECS Tuning | ||||||
| 01 | Right roof frame gasket | 1 | 51718233798 | ENDED | Shop at ECS Tuning | |||||
| 02 | Edge protection front | 2 | 51728196289 | $73.16 | Shop at ECS Tuning | |||||
| 03 | Inner left window channel cover | 1 | 51218174763 | $18.00 | Shop at ECS Tuning | |||||
| 03 | Inner right window channel cover | 1 | 51218174764 | $18.00 | Shop at ECS Tuning | |||||
| 04 | Outer weatherstrip, left | 1 | 51211960647 | $32.85 | Shop at ECS Tuning | |||||
| 04 | Outer weatherstrip, right | 1 | 51211960648 | $32.85 | Shop at ECS Tuning | |||||
| 05 | Clamp | X | 51211977747 | $1.11 | Shop at ECS Tuning | |||||
| 06 | Rear left sealing betw.door and column | 1 | 51718221199 | $29.82 | Shop at ECS Tuning | |||||
| 06 | Rear right sealing betw.door and column | 1 | 51718221200 | Shop at ECS Tuning | ||||||
| 07 | Gasket f lateral roof cover | 2 | 51718190365 | ENDED | Shop at ECS Tuning | |||||
| 09 | Grommet | D=17,5MM | 2 | 54128211460 | $2.65 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
