Single components for body-side frame for BMW 3 Series E36 323i (1999)
This Single components for body-side frame technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 323i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1999.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Left side member | 1 | 41128119251 | $86.81 | ENDED | Shop at ECS Tuning | ||||
| 01 | Right side member | 1 | 41128119252 | $86.81 | ENDED | Shop at ECS Tuning | ||||
| 02 | Rear left side member | 1 | 41118132991 | $120.63 | ENDED | Shop at ECS Tuning | ||||
| 02 | Right rear side member | 1 | 41118132992 | $120.63 | ENDED | Shop at ECS Tuning | ||||
| 03 | Left interior column C | 1 | 41218191701 | ENDED | Shop at ECS Tuning | |||||
| 03 | Right interior column C | 1 | 41218191702 | ENDED | Shop at ECS Tuning | |||||
| 04 | Left interior column D | 1 | 41218191703 | Shop at ECS Tuning | ||||||
| 04 | Right interior column D | 1 | 41218191704 | ENDED | Shop at ECS Tuning | |||||
| 05 | Left rear lateral roof cover | 1 | 41358193189 | ENDED | Shop at ECS Tuning | |||||
| 05 | Right rear lateral roof cover | 1 | 41358193190 | ENDED | Shop at ECS Tuning | |||||
| 06 | Lock | HELLGRAU | 4 | 51718151431 | $0.85 | Shop at ECS Tuning | ||||
| 06 | Lock | DUNKELGRAU | 4 | 51718151432 | $6.18 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
