Mounting parts for trunk floor panel for BMW 6 Series E24 633CSi (1982)
This Mounting parts for trunk floor panel technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 633CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1982.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Floor panel trunk lateral | BASIS | 1 | 41001930967 | $691.14 | ENDED, +core | Shop at ECS Tuning | |||
| 01 | Floor panel trunk lateral | BASIS | 1 | 41121942043 | $380.98 | ENDED | Shop at ECS Tuning | |||
| 02 | Cross member left | 1 | 41111979033 | $298.30 | Shop at ECS Tuning | |||||
| 03 | Cross member right | 1 | 41111979034 | $298.30 | ENDED | Shop at ECS Tuning | ||||
| 04 | Floor panel trunk lateral | BASIS | 1 | 41001930968 | $487.69 | ENDED | Shop at ECS Tuning | |||
| 04 | Floor panel trunk lateral | BASIS | 1 | 41121942044 | $384.87 | ENDED | Shop at ECS Tuning | |||
| 05 | Bracket center | 1 | 41121915748 | $14.17 | ENDED | Shop at ECS Tuning | ||||
| 06 | Bracket left | 1 | 41121834727 | $29.90 | ENDED | Shop at ECS Tuning | ||||
| 06 | Bracket right | 1 | 41121976606 | $14.17 | Shop at ECS Tuning | |||||
| 09 | Bow | 1 | 18211246056 | $2.88 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
