Body-side frame rear for BMW 6 Series E24 633CSi (1979)
This Body-side frame rear technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 633CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1979.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Side member left | 1 | 09/1982 | 41211861001 | $867.69 | ENDED | Shop at ECS Tuning | |||
| 01 | Side member right | 1 | 09/1982 | 41211861002 | $867.69 | ENDED | Shop at ECS Tuning | |||
| 02 | Lateral body part rear bottom left | 1 | 41211839979 | $351.54 | ENDED | Shop at ECS Tuning | ||||
| 02 | Lateral body part rear bottom right | 1 | 41211839980 | $385.02 | Shop at ECS Tuning | |||||
| For vehicles with Lift-up-and-slide-back sunroof |
=Yes |
|||||||||
| 03 | Support | 2 | 41211866663 | ENDED | Shop at ECS Tuning | |||||
| 04 | Support | 2 | 41211866664 | $13.28 | ENDED | Shop at ECS Tuning | ||||
| 05 | Connection piece left | 1 | 41351839971 | ENDED | Shop at ECS Tuning | |||||
| 05 | Connection piece right | 1 | 41351839972 | ENDED | Shop at ECS Tuning | |||||
| 06 | Lateral body part rear top left | 1 | 41211839977 | ENDED | Shop at ECS Tuning | |||||
| 06 | Lateral body part rear top right | 1 | 41211839978 | ENDED | Shop at ECS Tuning | |||||
| 07 | Wheel arch outer rear left | 1 | 09/1982 | 41211839975 | $545.72 | ENDED | Shop at ECS Tuning | |||
| 07 | Wheel arch outer rear right | 1 | 09/1982 | 41211839976 | $545.72 | Shop at ECS Tuning | ||||
| 08 | Reinforcement left | 1 | 11/1985 | 41211839981 | $368.28 | Shop at ECS Tuning | ||||
| 08 | Reinforcement right | 1 | 11/1985 | 41211839982 | $368.28 | ENDED | Shop at ECS Tuning | |||
| 08 | Reinforcement left | 1 | 41211942051 | $407.34 | ENDED | Shop at ECS Tuning | ||||
| 08 | Reinforcement right | 1 | 41211942052 | $407.34 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with Lift-up-and-slide-back sunroof |
=Yes |
|||||||||
| 09 | Bracket | 1 | 41351865199 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
