Rear window frame for BMW 3 Series E21 320i (1977)
This Rear window frame technical drawing provides a detailed breakdown of the assembly for the 3 Series E21 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1977.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Rear window frame | 1 | 41321887420 | $245.52 | ENDED | Shop at ECS Tuning | ||||
| 02 | Rear window frame left | 1 | 41321887423 | $149.54 | ENDED | Shop at ECS Tuning | ||||
| 03 | Rear window frame bottom part | 1 | 41321847425 | $42.48 | ENDED | Shop at ECS Tuning | ||||
| 04 | Rear window frame right | 1 | 41321887424 | $89.84 | ENDED | Shop at ECS Tuning | ||||
| 05 | Rear window frame upper part | 1 | 41321846686 | $33.48 | ENDED | Shop at ECS Tuning | ||||
| 06 | Covering panel rear window frame | 1 | 41321865007 | $91.23 | Shop at ECS Tuning | |||||
| 07 | Connection piece left | 1 | 41321846691 | $15.74 | ENDED | Shop at ECS Tuning | ||||
| 07 | Connection piece right | 1 | 41321846692 | $17.19 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
