Apron for BMW 3 Series E30 320i (1991)
This Apron technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1991.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Roof cover | 1 | 41311913761 | $470.01 | ENDED | Shop at ECS Tuning | ||||
| 01 | Roof covering lifting-sliding roof | 1 | 41311936229 | $755.38 | ENDED | Shop at ECS Tuning | ||||
| 02 | Roof frame left | 1 | 41221911159 | $77.79 | ENDED | Shop at ECS Tuning | ||||
| 02 | Right roof frame | 1 | 41221911160 | $77.79 | ENDED | Shop at ECS Tuning | ||||
| 03 | Roof frame left | 1 | 41221913767 | $39.06 | ENDED | Shop at ECS Tuning | ||||
| 03 | Right roof frame | 1 | 41221913768 | $39.06 | ENDED | Shop at ECS Tuning | ||||
| 04 | Connection plate roof center left | 1 | 41221913769 | $15.26 | ENDED | Shop at ECS Tuning | ||||
| 04 | Connection plate roof center right | 1 | 41221913770 | $24.52 | ENDED | Shop at ECS Tuning | ||||
| 05 | Connection plate roof front left | 1 | 41321913771 | $15.36 | ENDED | Shop at ECS Tuning | ||||
| 05 | Connection plate roof front right | 1 | 41321913772 | $15.36 | ENDED | Shop at ECS Tuning | ||||
| 06 | Left apron | 1 | 41321913773 | $24.86 | ENDED | Shop at ECS Tuning | ||||
| 06 | Right apron | 1 | 41321913774 | $24.86 | ENDED | Shop at ECS Tuning | ||||
| 07 | Upper apron | 1 | 41321913766 | $37.10 | Shop at ECS Tuning | |||||
| 08 | Roof frame left | 1 | 41221913775 | $36.27 | ENDED | Shop at ECS Tuning | ||||
| 08 | Right roof frame | 1 | 41221913776 | $35.38 | ENDED | Shop at ECS Tuning | ||||
| 09 | Upper apron | 1 | 41321913777 | $37.10 | Shop at ECS Tuning | |||||
| 10 | Inner left apron | 1 | 41321913781 | $50.50 | ENDED | Shop at ECS Tuning | ||||
| 10 | Inner right apron | 1 | 41321913782 | $29.57 | Shop at ECS Tuning | |||||
| 11 | Rear window frame left | 1 | 41321913783 | $28.04 | Shop at ECS Tuning | |||||
| 11 | Rear window frame right | 1 | 41321913784 | $26.36 | ENDED | Shop at ECS Tuning | ||||
| 12 | Rear window frame upper part | 1 | 41321913780 | $28.04 | Shop at ECS Tuning | |||||
| 13 | Roof bow | 1 | 41321913762 | $37.10 | ENDED | Shop at ECS Tuning | ||||
| 14 | Apron | 1 | 41321913778 | $56.41 | Shop at ECS Tuning | |||||
| 15 | Covering panel rear window frame | 1 | 41321913806 | $58.59 | ENDED | Shop at ECS Tuning | ||||
| 15 | Covering panel rear window frame | 1 | 41328100499 | $58.42 | Shop at ECS Tuning | |||||
| 16 | Rear window frame bottom part | 1 | 09/1987 | 41111972568 | $49.52 | ENDED | Shop at ECS Tuning | |||
| 17 | Reinforcement left | 1 | 41221929401 | $3.46 | ENDED | Shop at ECS Tuning | ||||
| 17 | Reinforcement right | 1 | 41221929402 | $3.46 | ENDED | Shop at ECS Tuning | ||||
| 18 | Blind plug | D=20MM | 3 | 51711801066 | $0.23 | Shop at ECS Tuning |
