Locking system, door, front for BMW 3 Series E21 323i (1982)
This Locking system, door, front technical drawing provides a detailed breakdown of the assembly for the 3 Series E21 323i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1982.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Remote control left | 1 | 51211800665 | $9.77 | Shop at ECS Tuning | |||||
| 01 | Remote control right | 1 | 51211800666 | $9.77 | Shop at ECS Tuning | |||||
| 02 | Washer | 5.3-140 HV-ZNS | 6 | 07119936439 | $0.40 | Shop at ECS Tuning | ||||
| 03 | Tooth washer | A5,1 | 6 | 07119936107 | $0.18 | Shop at ECS Tuning | ||||
| 04 | Hex bolt | M5X8 | 6 | 07119913212 | $0.25 | Shop at ECS Tuning | ||||
| 05 | Handle | 2 | 51211847415 | $21.46 | Shop at ECS Tuning | |||||
| 06 | Cover | 2 | 51211847416 | $1.98 | ENDED | Shop at ECS Tuning | ||||
| 07 | Conical screw | 2 | 51211800790 | $0.67 | Shop at ECS Tuning | |||||
| 08 | Cover | 2 | 51211800789 | $0.55 | Shop at ECS Tuning | |||||
| 09 | Self-locking hex nut | M6 | 4 | 07147153450 | $0.47 | Shop at ECS Tuning | ||||
| 10 | Base plate left | 1 | 51211827257 | $27.31 | ENDED | Shop at ECS Tuning | ||||
| 10 | Base plate right | 1 | 51211827258 | $27.31 | Shop at ECS Tuning | |||||
| 11 | Sleeve | 2 | 51211802016 | $7.57 | ENDED | Shop at ECS Tuning | ||||
| 12 | Lock plate | 2 | 51211832811 | $6.31 | Shop at ECS Tuning | |||||
| 13 | Distance rubber | D=6MM | 4 | 51216742120 | $1.25 | Shop at ECS Tuning | ||||
| 14 | Handle | 2 | 51211919083 | $17.31 | ENDED | Shop at ECS Tuning | ||||
| 15 | Fillister head screw | M4X10-Z5 | 4 | 51211916992 | $0.58 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
