Rear spoiler single parts for BMW 5 Series E12 520 (1981)
This Rear spoiler single parts technical drawing provides a detailed breakdown of the assembly for the 5 Series E12 520. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1981.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 02 | Rear spoiler | MOTORSPORT | 1 | 51712205437 | $608.22 | ENDED | Shop at ECS Tuning | |||
| 03 | Washer | 4-200 HV-ZNS3 | 4 | 07119904207 | Shop at ECS Tuning | |||||
| 04 | Hex nut | M4-A2-70 | 4 | 07129906098 | $1.00 | Shop at ECS Tuning | ||||
| 05 | Blind plug | D=20MM | 2 | 51711801066 | $0.23 | Shop at ECS Tuning | ||||
| 06 | Blind plug | 2 | 41355780222 | $0.40 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E12 520 Rear spoiler single parts?
- This technical diagram illustrates the Rear spoiler single parts within the Bodywork group for the 5 Series E12 520 produced during 1981. It provides a detailed exploded view of the components, identifying key parts such as the Rear spoiler (Part #51712205437).
- Which models use the hardware listed in this Rear spoiler single parts?
- The hardware and components featured in the Rear spoiler single parts are specific to the 5 Series E12 520 produced during 1981. These technical specifications ensure that parts like the Rear spoiler (51712205437) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Rear spoiler single parts assembly?
- Each item in the Rear spoiler single parts corresponds to the numbered list below the illustration. For the 5 Series E12 520, you can identify the Rear spoiler by locating its position on the schematic, which then links to the official BMW part number 51712205437 for the Bodywork section.
