Partition trunk for BMW 8 Series E31 850Ci (1994)
This Partition trunk technical drawing provides a detailed breakdown of the assembly for the 8 Series E31 850Ci. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1994.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Partition trunk | 1 | 41138108481 | $545.72 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with foldable backrest |
=Yes |
|||||||||
| 02 | Bracket backrest outer right | 1 | 09/1992 | 41148134989 | $18.30 | Shop at ECS Tuning | ||||
| 02 | Bracket backrest inner right | 1 | 09/1992 | 41148134990 | $18.30 | Shop at ECS Tuning | ||||
| 03 | Bracket backrest outer left | 1 | 09/1992 | 41148134987 | $15.74 | Shop at ECS Tuning | ||||
| 03 | Bracket backrest outer right | 1 | 09/1992 | 41148134988 | $15.74 | Shop at ECS Tuning | ||||
| 04 | Upper backrest bearing bracket | 2 | 09/1992 | 41148134986 | $13.06 | Shop at ECS Tuning | ||||
| 05 | Spring left | 2 | 09/1992 | 52208164567 | $8.93 | Shop at ECS Tuning | ||||
| 05 | Spring right | 2 | 09/1992 | 52208164568 | $8.93 | Shop at ECS Tuning | ||||
| 06 | Spring clip | 4 | 09/1992 | 52208164569 | $0.69 | Shop at ECS Tuning | ||||
| 07 | Fillister-head screw | M5 X 16 | 4 | 09/1992 | 52208170990 | $0.46 | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
