Door handle front/lock/key for BMW 8 Series E31 850Ci (1994)
This Door handle front/lock/key technical drawing provides a detailed breakdown of the assembly for the 8 Series E31 850Ci. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1994.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Information regarding remote control: Basic = remote control 433 MHZ SA 876 = remote control 315 MHZ SA 875 = infrared remote control |
|||||||||
| FOR VEHICLES WITH AND WITHOUT DOOR LOCK HEATING |
||||||||||
| 01 | Lock with code, left | 1 | 51218160907 | $277.53 | ENDED | Shop at ECS Tuning | ||||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 01 | Catch with key code right | 1 | 51218160908 | $277.53 | ENDED | Shop at ECS Tuning | ||||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 01 | Catch with key left | 1 | 51218160909 | $300.82 | ENDED | Shop at ECS Tuning | ||||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 01 | Catch with key right | 1 | 51218160910 | $300.82 | ENDED | Shop at ECS Tuning | ||||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 01 | Lock with code, left | BMW INDIVIDUAL | 1 | 51218160921 | $301.13 | ENDED | Shop at ECS Tuning | |||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 01 | Catch with key code right | BMW INDIVIDUAL | 1 | 51218160922 | $258.91 | ENDED | Shop at ECS Tuning | |||
| Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. |
||||||||||
| 02 | General key w/out light compartm.(code) | X | 01/1995 | 51211954400 | $37.40 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| 02 | Universal key | (ROHLING) | X | 01/1995 | 51218154998 | $24.93 | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | Light storage compartment | X | 01/1995 | 51218105039 | $22.38 | Shop at ECS Tuning | ||||
| 03 | General key (code) | X | 01/1995 | 51211950662 | $37.40 | Shop at ECS Tuning | ||||
| 03 | Universal key | X | 01/1995 | 51211950666 | $24.93 | Shop at ECS Tuning | ||||
| 04 | Service key (code) | X | 01/1995 | 51211950660 | $29.90 | Shop at ECS Tuning | ||||
| 04 | Service key (blank) | X | 01/1995 | 51211950664 | $19.93 | Shop at ECS Tuning | ||||
| 05 | Spare key (code) | X | 01/1995 | 51211950663 | $29.90 | Shop at ECS Tuning | ||||
| 05 | Spare key (blank) | X | 01/1995 | 51211950667 | $19.93 | Shop at ECS Tuning | ||||
| 08 | Light storage compartment | 1 | 01/1995 | 51218105039 | $22.38 | Shop at ECS Tuning | ||||
| 09 | Bulb | 0.13W | 1 | 01/1995 | 51211935001 | $3.00 | Shop at ECS Tuning | |||
| ONLY APPLIES TO LIGHT STORAGE COMPARTMENT The battery is to be installed directly in the corresponding control unit/key on site. It is not permitted to sell the battery if it is not installed. Old batteries must be properly disposed of. |
||||||||||
| 10 | Battery | 1,5 V - PX625A | 1 | 01/1995 | 32321151013 | $8.03 | Shop at ECS Tuning | |||
| For vehicles with Radio remote control The battery is to be installed directly in the corresponding control unit/key on site. It is not permitted to sell the battery if it is not installed. Old batteries must be properly disposed of. |
=Yes |
|||||||||
| 10 | Battery | 3,0 V - CR1220 | 2 | 02/1992 | 09/1996 | 61358364946 | $8.03 | Shop at ECS Tuning | ||
| 11 | Cover | 1 | 02/1992 | 51218354414 | $9.93 | Shop at ECS Tuning | ||||
| 13 | Countersunk head screw | 2,2X7 | 2 | 02/1992 | 66218354639 | $0.50 | Shop at ECS Tuning | |||
| 16 | Key case | 1 | 51218213607 | $9.15 | Shop at ECS Tuning | |||||
| For vehicles with Remote control |
=Yes |
|||||||||
| 16 | Key case | 1 | 02/1992 | 51217006821 | $17.32 | Shop at ECS Tuning | ||||
| For vehicles with Radio remote control |
=Yes |
|||||||||
| 18 | Master key with remote control (code) | 315 MHZ | X | 01/1995 | 51218366369 | $155.10 | ENDED | Shop at ECS Tuning | ||
| ONLY IN CONJUNCTION WITH RADIO REMOTE CONTROL COVER |
||||||||||
| 18 | Master key with remote control (blank) | 315 MHZ | X | 01/1995 | 51218366374 | $122.45 | ENDED | Shop at ECS Tuning | ||
| ONLY IN CONJUNCTION WITH RADIO REMOTE CONTROL COVER |
||||||||||
Notes
- ENDED = the part has been discontinued (no longer available).
