Front door-hinge/door brake for BMW 1500-2000CS 1800 (1971)
This Front door-hinge/door brake technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 1800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Remote control left | 1 | 01/1969 | 01/1972 | 51211800665 | $9.77 | Shop at ECS Tuning | |||
| 01 | Remote control right | 1 | 01/1969 | 01/1972 | 51211800666 | $9.77 | Shop at ECS Tuning | |||
| 03 | Handle left | 1 | 01/1969 | 01/1972 | 51211806003 | $38.11 | Shop at ECS Tuning | |||
| 03 | Handle right | 1 | 01/1969 | 01/1972 | 51211806004 | $38.11 | Shop at ECS Tuning | |||
| 04 | Covering left | 1 | 01/1969 | 01/1972 | 51211803751 | $4.61 | Shop at ECS Tuning | |||
| 04 | Covering right | 1 | 01/1969 | 01/1972 | 51211803752 | $4.61 | Shop at ECS Tuning | |||
| 06 | Hex bolt | M5X12-8.8 ZN | 6 | 07119913231 | $1.42 | Shop at ECS Tuning | ||||
| 07 | Tooth washer | A5,1 | 6 | 07119936107 | $0.18 | Shop at ECS Tuning | ||||
| 08 | Washer | A6,4-200HV-ZNS3 | 6 | 07119903791 | $0.11 | Shop at ECS Tuning | ||||
| 09 | Grommet | 2 | 52208238999 | $0.40 | Shop at ECS Tuning | |||||
| 10 | Connection rod | 2 | 51211804641 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
