Front door-hinge/door brake for BMW 1500-2000CS 2000C (1968)
This Front door-hinge/door brake technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 2000C. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1968.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Grommet | 6 | 52208238999 | $0.40 | Shop at ECS Tuning | |||||
| Early version | ||||||||||
| 02 | Remote control | 1 | 51216742110 | $19.55 | ENDED | Shop at ECS Tuning | ||||
| Late version | ||||||||||
| 02 | Remote control | 1 | 51211811151 | ENDED | Shop at ECS Tuning | |||||
| 02 | Remote control right | 1 | 51211811152 | ENDED | Shop at ECS Tuning | |||||
| 04 | Handle left | 1 | 51211806003 | $38.11 | Shop at ECS Tuning | |||||
| 04 | Handle right | 1 | 51211806004 | $38.11 | Shop at ECS Tuning | |||||
| 06 | Hex bolt | M5X15 | 10 | 07119913235 | $3.51 | ENDED | Shop at ECS Tuning | |||
| 07 | Set tooth washer 25 | A5,1 | 6 | 07509064286 | ENDED | Shop at ECS Tuning | ||||
| Early version | ||||||||||
| 09 | Catch front left | 1 | 51216742104 | ENDED | Shop at ECS Tuning | |||||
| 09 | Catch front right | 1 | 51216742105 | ENDED | Shop at ECS Tuning | |||||
| 11 | Grommet | 2 | 51416440264 | ENDED | Shop at ECS Tuning | |||||
| 12 | Lock button | SCHWARZ | 2 | 51211805643 | $1.26 | Shop at ECS Tuning | ||||
| 13 | Bump stop | 2 | 51211809735 | $1.36 | Shop at ECS Tuning | |||||
| 14 | Hex bolt | M6X12-8.8-ZNNIV | 4 | 07119905524 | $0.27 | Shop at ECS Tuning | ||||
| 14 | Set csk.fillister head screw 25 | M6X12 | 2 | 07509063235 | ENDED | Shop at ECS Tuning | ||||
| 15 | Bush | 4 | 51216642022 | $1.13 | ENDED | Shop at ECS Tuning | ||||
| 16 | Rubber buffer | 1 | 51216642010 | $3.94 | ENDED | Shop at ECS Tuning | ||||
| 16 | Rubber buffer | 1 | 51216642011 | ENDED | Shop at ECS Tuning | |||||
| 17 | Roller | 2 | 51216642021 | ENDED | Shop at ECS Tuning | |||||
| 18 | Spacer sleeve | 2 | 51216642023 | ENDED | Shop at ECS Tuning | |||||
| 19 | Connection rod | 2 | 51216742114 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
