Remote RF control / ELV for BMW 5 Series E60 LCI 530i (2009)
This Remote RF control / ELV technical drawing provides a detailed breakdown of the assembly for the 5 Series E60 LCI 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2009.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Important notice! Before ordering keys, central locking systems, control units (EWS immobilizer/CAS), etc., it is vital to ensure that the customer and/or vehicle owner present proof of authorization in the form of original vehicle documents and an official photo ID! A power of attorney from the vehicle owner is also required for authorised third parties. Copies of the specified credentials (proof of authorisation) must be kept in the vehicle records. Please inform BMW Service immediately if a vehicle key is lost so it can be deactivated in order to avoid taking the risk of losing the insurance cover due to gross negligence in the event of a theft. --------------------------- Information on remote control: Basis = radio remote control 868 MHZ Japan/Korea = radio remote control 315 MHZ Low-power SA 876 = radio remote control 315 MHZ SA 874 = radio remote control 434 MHZ |
|||||||||
| For vehicles with Comfort access and Radio frequency 315 MHz |
S322A=No S876A=Yes |
|||||||||
| 01 | Radio remote control | 315 MHZ | 2 | 03/2007 | 66126986583 | $130.60 | Shop at ECS Tuning | |||
| For vehicles with Comfort access and Radio frequency 434 MHz |
S322A=Yes S874A=Yes |
|||||||||
| 01 | Radio remote control PCA | 434 MHZ | 2 | 03/2007 | 66129268489 | Shop at ECS Tuning | ||||
| For vehicles with National version Korea and Comfort access |
L802A=Yes S322A=Yes |
|||||||||
| 01 | Radio remote control PCA | 315 MHZ LOW POW | 2 | 03/2007 | 66126986580 | Shop at ECS Tuning | ||||
| For vehicles with National version Korea and Comfort access |
L802A=Yes S322A=No |
|||||||||
| 01 | Radio remote control | 315 MHZ LOW POW | 2 | 03/2007 | 66126986584 | Shop at ECS Tuning | ||||
| For vehicles with Comfort access and Radio frequency 315 MHz |
S322A=Yes S876A=No |
|||||||||
| 01 | Radio remote control PCA | 868 MHZ | 2 | 03/2007 | 66129268488 | Shop at ECS Tuning | ||||
| For vehicles with Comfort access and Radio frequency 315 MHz |
S322A=Yes S876A=Yes |
|||||||||
| 01 | Radio remote control PCA | 315 MHZ | 2 | 03/2007 | 66129268486 | Shop at ECS Tuning | ||||
| For vehicles with Comfort access and Radio frequency 434 MHz |
S322A=No S874A=Yes |
|||||||||
| 01 | Radio remote control | 434 MHZ | 2 | 03/2007 | 66126986582 | Shop at ECS Tuning | ||||
| For vehicles with Comfort access and Radio frequency 434 MHz and Radio frequency 315 MHz |
S322A=No S874A=No S876A=No |
|||||||||
| 01 | Radio remote control | 868 MHZ | 2 | 03/2007 | 66126986585 | Shop at ECS Tuning | ||||
| For vehicles with National version japan and Comfort access and Radio frequency 315 MHz |
L807A=Yes S322A=Yes S876A=Yes |
|||||||||
| 01 | Radio remote control PCA | 315 MHZ | 2 | 09/2008 | 66129268486 | Shop at ECS Tuning | ||||
| For vehicles with National version japan and Comfort access and Radio frequency 315 MHz |
L807A=Yes S322A=No S876A=Yes |
|||||||||
| 01 | Radio remote control | 315 MHZ | 2 | 09/2008 | 66126986583 | $130.60 | Shop at ECS Tuning | |||
| 02 | Integrated key | 2 | 03/2007 | 51217139710 | $25.46 | Shop at ECS Tuning | ||||
| 03 | Spare key | 1 | 03/2007 | 51217057672 | $40.71 | +core | Shop at ECS Tuning | |||
| For vehicles with National version Korea |
L802A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032902 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland |
L812A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 868 MHZ | 1 | 03/2007 | 51210032903 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Radio frequency 315 MHz |
L812A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032901 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with Comfort access and Radio frequency 434 MHz |
S322A=Yes S874A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 434 MHZ | 1 | 03/2007 | 51210032900 | Shop at ECS Tuning | ||||
| 04 | Set of keys with CAS control unit | 434 MHZ | 1 | 03/2007 | 51210032904 | Shop at ECS Tuning | ||||
| For vehicles with National version Korea and Comfort access |
L802A=Yes S322A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032906 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Comfort access |
L812A=Yes S322A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 868 MHZ | 1 | 03/2007 | 51210032907 | Shop at ECS Tuning | ||||
| For vehicles with National version japan and Radio frequency 315 MHz |
L807A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 09/2008 | 51210032901 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with Comfort access and Radio frequency 434 MHz |
S322A=No S874A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 434 MHZ | 1 | 03/2007 | 51210036013 | Shop at ECS Tuning | ||||
| For vehicles with Radio frequency 434 MHz and Radio frequency 315 MHz |
S874A=No S876A=No |
|||||||||
| 04 | Set of keys with CAS control unit | 868 MHZ | 1 | 03/2007 | 51210032903 | Shop at ECS Tuning | ||||
| For vehicles with National version japan and Comfort access and Radio frequency 315 MHz |
L807A=Yes S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 09/2008 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with Comfort access and Radio frequency 434 MHz and Radio frequency 315 MHz |
S322A=Yes S874A=No S876A=No |
|||||||||
| 04 | Set of keys with CAS control unit | 868 MHZ | 1 | 03/2007 | 51210032907 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Radio frequency 315 MHz |
L812A=No S205A=No S2TBA=No S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032901 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=No S205A=Yes S2TBA=Yes S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51215A45203 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=No S205A=Yes S2TBA=No S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51215A45203 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=No S205A=No S2TBA=Yes S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51215A45203 | Shop at ECS Tuning | ||||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=Yes S205A=Yes S2TBA=Yes S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=Yes S205A=Yes S2TBA=No S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=Yes S205A=No S2TBA=Yes S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=Yes S205A=No S2TBA=No S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| For vehicles with National version England / Ireland and Automatic transmission and Sport automatic transmission and Comfort access and Radio frequency 315 MHz |
L812A=No S205A=No S2TBA=No S322A=Yes S876A=Yes |
|||||||||
| 04 | Set of keys with CAS control unit | 315 MHZ | 1 | 03/2007 | 51210032905 | $394.92 | Shop at ECS Tuning | |||
| 06 | Label "Key Memory" | 1 | 03/2007 | 71239178687 | $4.67 | Shop at ECS Tuning | ||||
| For vehicles with Comfort access The battery is to be installed directly in the corresponding control unit/key on site. It is not permitted to sell the battery if it is not installed. Old batteries must be properly disposed of. |
S322A=Yes |
|||||||||
| 07 | Battery | 3,2 V - CR2032 | 1 | 03/2007 | 66126912985 | $8.38 | Shop at ECS Tuning | |||
| 08 | Adapter, spare key | 1 | 03/2007 | 66126937508 | $7.10 | Shop at ECS Tuning | ||||
Notes
- +core = plus core charge (possibility of a return of the old part)
