Trunk lid, mounting parts for BMW MINI F56 LCI JCW (2024)
This Trunk lid, mounting parts technical drawing provides a detailed breakdown of the assembly for the MINI F56 LCI JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Trunk lid sealing | 1 | 51767375849 | Shop at ECS Tuning | ||||||
| 02 | Primed rear spoiler | JOHN COOPER W. | 1 | 51627375850 | Shop at ECS Tuning | |||||
| 03 | Covering left | 1 | 51627360325 | Shop at ECS Tuning | ||||||
| 03 | Covering right | 1 | 51627360326 | Shop at ECS Tuning | ||||||
| 04 | Supporting ledge | 1 | 51627337600 | Shop at ECS Tuning | ||||||
| 05 | Trim strip, trunk lid/tailgate | 1 | 51137320540 | Shop at ECS Tuning | ||||||
| 06 | Mount rail, trim strip, trunk lid, left | 1 | 51137302545 | Shop at ECS Tuning | ||||||
| 06 | Mount rail, trim strip, trunk lid, right | 1 | 51137375104 | Shop at ECS Tuning | ||||||
| 07 | Travel stop | 2 | 51247340383 | Shop at ECS Tuning | ||||||
| 08 | Stop buffer | 2 | 51247340380 | Shop at ECS Tuning | ||||||
| 09 | Mount for jounce stop | 2 | 51247340381 | Shop at ECS Tuning | ||||||
| 10 | Fillister head screw | M6X16 8.8 | 3 | 51119907273 | Shop at ECS Tuning | |||||
| 11 | Blind rivet nut, flat headed | M6 | 3 | 51248226003 | $2.13 | Shop at ECS Tuning | ||||
| 12 | Screw | SECHSKANT | 2 | 07143428231 | $0.36 | Shop at ECS Tuning | ||||
| 13 | Expanding nut | 2 | 51127046911 | $0.48 | Shop at ECS Tuning | |||||
| 14 | Fillister head screw with collar | 5 | 07147187828 | $0.38 | Shop at ECS Tuning | |||||
| 15 | Slider | 5 | 51627401793 | Shop at ECS Tuning | ||||||
| For vehicles with Control of number-plate attachment |
S992A=Yes |
|||||||||
| 16 | License-plate carrier rear | US | 1 | 51139448724 | Shop at ECS Tuning | |||||
| 19 | Expanding nut | 8X8 MM | 2 | 51127020321 | $0.47 | Shop at ECS Tuning | ||||
| 20 | Screw | VS-TS5X16 SW | 2 | 51139908498 | Shop at ECS Tuning | |||||
