Glazing for BMW 3 Series E30 325ix (1992)
This Glazing technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325ix. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1992.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Front windshield clear | 1 | 51311876150 | $392.67 | Shop at ECS Tuning | |||||
| 01 | Green windshield | 1 | 51311884393 | $392.67 | Shop at ECS Tuning | |||||
| 01 | Green windscreen, green shade band | 1 | 51311884397 | $432.31 | Shop at ECS Tuning | |||||
| 02 | Door window green front left | 1 | 04/1988 | 51321962407 | $142.82 | Shop at ECS Tuning | ||||
| 02 | Door window green front right | 1 | 04/1988 | 51321962408 | $142.82 | Shop at ECS Tuning | ||||
| 03 | Door window, rear left | 1 | 04/1988 | 51341961727 | $141.33 | Shop at ECS Tuning | ||||
| 03 | Door window green rear right | 1 | 04/1988 | 51341961728 | $141.33 | Shop at ECS Tuning | ||||
| 04 | Fixed door window, green, left | 1 | 51341947133 | $51.89 | Shop at ECS Tuning | |||||
| 04 | Fixed door window, green, right | 1 | 51341947134 | $51.89 | Shop at ECS Tuning | |||||
| 05 | Side window, green, left | 1 | 51361947263 | Shop at ECS Tuning | ||||||
| 05 | Side window green right | 1 | 51361947264 | $199.76 | Shop at ECS Tuning | |||||
| 06 | Rear window green | 1 | 51311942969 | $397.36 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 325ix Glazing?
- This technical diagram illustrates the Glazing within the Vehicle trim group for the 3 Series E30 325ix produced during 1992. It provides a detailed exploded view of the components, identifying key parts such as the Front windshield clear (Part #51311876150).
- Which models use the hardware listed in this Glazing?
- The hardware and components featured in the Glazing are specific to the 3 Series E30 325ix produced during 1992. These technical specifications ensure that parts like the Front windshield clear (51311876150) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Glazing assembly?
- Each item in the Glazing corresponds to the numbered list below the illustration. For the 3 Series E30 325ix, you can identify the Front windshield clear by locating its position on the schematic, which then links to the official BMW part number 51311876150 for the Vehicle trim section.
