Door window lifting mechanism front for BMW 3 Series E21 320 (1979)
This Door window lifting mechanism front technical drawing provides a detailed breakdown of the assembly for the 3 Series E21 320. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1979.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | DOOR WINDOW LIFTING MECHANISM | |||||||||
| 01 | Hex bolt with washer | M6X12-U2-8.8 | 4 | 08/1979 | 07119904459 | $0.65 | Shop at ECS Tuning | |||
| 02 | Track rail | 2 | 08/1979 | 51321822945 | $12.95 | Shop at ECS Tuning | ||||
| 03 | Hex bolt with washer | M6X16-U2-ZNS3 | 6 | 08/1979 | 07119902913 | Shop at ECS Tuning | ||||
| 04 | Guide rail front left | 1 | 08/1979 | 51321823967 | $11.49 | ENDED | Shop at ECS Tuning | |||
| 04 | Guide rail front right | 1 | 08/1979 | 51321823968 | $12.13 | ENDED | Shop at ECS Tuning | |||
| 05 | Filling rubber | 2 | 08/1979 | 51321864309 | $0.89 | ENDED | Shop at ECS Tuning | |||
| 06 | Covering left | 1 | 08/1979 | 51321834717 | ENDED | Shop at ECS Tuning | ||||
| 06 | Covering right | 1 | 08/1979 | 51321834718 | $25.95 | ENDED | Shop at ECS Tuning | |||
| 07 | Csk.lenshead screw | ST3,9X9,5 | 4 | 08/1979 | 07119902216 | $0.14 | ENDED | Shop at ECS Tuning | ||
| 08 | Blind plug | 2 | 08/1979 | 51321840819 | $0.13 | ENDED | Shop at ECS Tuning | |||
| 10 | Guide rail rear left | 1 | 08/1979 | 51321823945 | $20.87 | Shop at ECS Tuning | ||||
| 10 | Guide rail rear right | 1 | 08/1979 | 51321823946 | $12.10 | Shop at ECS Tuning | ||||
| 12 | Left One-piece window guide | 1 | 08/1979 | 51321880439 | $87.36 | ENDED | Shop at ECS Tuning | |||
| 12 | Right One-piece window guide | 1 | 08/1979 | 51321880440 | $87.36 | Shop at ECS Tuning | ||||
| 13 | Holder | 1 | 08/1979 | 41511870878 | $1.65 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
