Door window lifting mechanism rear for BMW 3 Series E30 325i (1989)
This Door window lifting mechanism rear technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 325i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1989.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Window lifter rear left | 1 | 03/1988 | 51341935635 | $75.14 | Shop at ECS Tuning | ||||
| 01 | Window lifter rear right | 1 | 03/1988 | 51341935636 | $75.14 | ENDED | Shop at ECS Tuning | |||
| 02 | Hex bolt with washer | M6X12-U1-8.8 | X | 03/1988 | 07119904517 | $0.36 | Shop at ECS Tuning | |||
| 03 | Fillister-head screw | 4 | 03/1988 | 51341961320 | $0.94 | Shop at ECS Tuning | ||||
| 04 | Electr.window lifter rear left | 1 | 03/1988 | 51351935639 | $253.00 | Shop at ECS Tuning | ||||
| 04 | Electr.window lifter rear right | 1 | 03/1988 | 51351935640 | $253.00 | Shop at ECS Tuning | ||||
| 05 | Hex nut with plate | M6 ZNT | X | 03/1988 | 07149156628 | $0.25 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
