Decorating stripes authorities for BMW 5 Series E28 535i (1987)
This Decorating stripes authorities technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 535i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1987.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Official vehicles |
=Yes |
|||||||||
| 01 | Foil left | 1 | 51141905011 | ENDED | Shop at ECS Tuning | |||||
| 01 | Foil right | 1 | 51141905012 | ENDED | Shop at ECS Tuning | |||||
| 02 | Foil left | 1 | 51141905013 | ENDED | Shop at ECS Tuning | |||||
| 02 | Foil right | 1 | 51141905014 | ENDED | Shop at ECS Tuning | |||||
| 03 | Foil left | 1 | 51141905015 | ENDED | Shop at ECS Tuning | |||||
| 03 | Foil right | 1 | 51141905016 | ENDED | Shop at ECS Tuning | |||||
| 04 | Foil left | 1 | 51141905017 | ENDED | Shop at ECS Tuning | |||||
| 04 | Foil right | 1 | 51141905018 | ENDED | Shop at ECS Tuning | |||||
| 05 | Foil tail panel | 1 | 51141905019 | ENDED | Shop at ECS Tuning | |||||
| 07 | Foil | 1 | 51141905020 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
